Item Name:37GB Circular eccentric shaft gear reduction gear motor
Model:YLT37GB-555
Description:
Operating relative humidity:20%-85%
Operating temperature:-10’C~+60’C
Characteristic:
1.Special axis core can be customized.
2.Select all-metal gear,with the merit of strong torque,long life etc.
4.Typical applications:Parking lock,advertising equipment,small machinery etc.
This Item Include:
1 x DC MOTOR
Geared Motor Specification:
|
Gearbox Length |
20.5 |
23.5 |
26.0 |
30.0 |
33.0 |
||||||||||
|
|
Reduction ratio |
1/10 |
1/18 |
1/30 |
1/50 |
1/60 |
1/75 |
1/90 |
1/150 |
1/200 |
1/270 |
1/300 |
1/500 |
1/750 |
1/810 |
|
12.0V |
Unload speed (RPM) |
600 |
333 |
200 |
120 |
100 |
80 |
65 |
40 |
30 |
22 |
20 |
12 |
8.0 |
7.5 |
|
Rated torque (KG-CM) |
1.0 |
1.0 |
2.0 |
3.0 |
3.0 |
4.0 |
6.0 |
7.0 |
7.5 |
8.0 |
8.0 |
9.0 |
9.0 |
10.0 |
|
|
Rated speed (RPM) |
528 |
313 |
109 |
100 |
95 |
76 |
54 |
36 |
29 |
18 |
19.5 |
11.5 |
7.8 |
6.0 |
|
|
24.0V |
Unload speed (RPM) |
600 |
333 |
200 |
120 |
100 |
80 |
65 |
40 |
30 |
22 |
20 |
12 |
8.0 |
7.5 |
|
Rated torque (KG-CM) |
1.0 |
1.0 |
2.0 |
3.0 |
3.0 |
4.0 |
6.0 |
7.0 |
7.5 |
8.0 |
8.0 |
9.0 |
9.0 |
10.0 |
|
|
Rated speed (RPM) |
532 |
315 |
186 |
109 |
96 |
77 |
55 |
36 |
29.5 |
18 |
19.8 |
11.8 |
7.8 |
6.0 |
|
Install Motor Specification:
|
Rated volt (V) |
Rated torque (g-cm) |
Rated speed (rpm) |
Rated current (mA) |
Unload speed (rpm) |
Unload current (mA) |
Rated output (W) |
Weight (g) |
|
12.0 |
250 |
4930 |
≤1600 |
6000 |
≤250 |
12.8 |
220 |
|
24.0 |
250 |
5150 |
≤750 |
6000 |
≤130 |
12.7 |
220 |
Notice:
1.The electric speed value of the geared motor is torque value and fixed reference value.
2.We accept special design and orders except standard products.
