Item Name:40GP Planetary Gear Motor
Model:YLT40GP-555
Description:
Operating relative humidity:20%-85%
Operating temperature:-10’C~+60’C
Characteristic:
1.Special axis core can be customized.
2.Select all-metal gear,with the merit of strong torque,long life etc.
4.Typical applications: Automatic curtains,robots,office equipment etc.
This Item Include:
1 x DC MOTOR
Geared Motor Specification:
|
Gearbox Length |
26.7 |
37.5 |
48.0 |
|||||||
|
|
Reduction ratio |
1/3.7 |
1/5.2 |
1/14 |
1/19 |
1/27 |
1/51 |
1/71 |
1/100 |
1/139 |
|
12.0V |
Unload speed (RPM) |
1620 |
1153 |
428 |
315 |
222 |
117 |
84 |
60 |
43 |
|
Rated torque (KG-CM) |
0.7 |
1.0 |
2.6 |
3.5 |
5.0 |
9.0 |
12.0 |
18.0 |
25 |
|
|
Rated speed (RPM) |
1324 |
948 |
350 |
258 |
180 |
96 |
69 |
49 |
35 |
|
|
24.0V |
Unload speed (RPM) |
1620 |
1153 |
428 |
315 |
222 |
117 |
84 |
60 |
43 |
|
Rated torque (KG-CM) |
0.7 |
1.0 |
2.6 |
3.5 |
5.0 |
9.0 |
12.0 |
15.0 |
22 |
|
|
Rated speed (RPM) |
1375 |
980 |
364 |
268 |
188 |
100 |
72 |
51 |
37 |
|
Install Motor Specification:
|
Rated volt (V) |
Rated torque (g-cm) |
Rated speed (rpm) |
Rated current (mA) |
Unload speed (rpm) |
Unload current (mA) |
Rated output (W) |
Weight (g) |
|
12.0 |
250 |
4930 |
≤1600 |
6000 |
≤250 |
12.8 |
220 |
|
24.0 |
250 |
5150 |
≤750 |
6000 |
≤130 |
12.7 |
220 |
Notice:
1.The electric speed value of the geared motor is torque value and fixed reference value.
2.We accept special design and orders except standard products.
